ASUS ROG Rampage V Edition 10 Motherboard - LGA 2011-v3, Intel X99, DDR4, E-ATX

The ASUS ROG Rampage V Edition 10 motherboard is a high-performance E-ATX solution designed for gamers and enthusiasts utilizing Intel's Core i7 processors. Built on the Intel X99 chipset, this motherboard supports advanced features that enhance gaming performance, overclocking capabilities, and overall system stability.

Key Features:

• Socket Type: LGA 2011-v3
• Chipset: Intel® X99
• Form Factor: E-ATX (272 x 305 mm)

CPU Support:

• Supports Intel® Core™ i7 processors with up to 10 cores.
• Compatible with both 28-lane and 40-lane CPU options.
• Utilizes Intel® Turbo Boost Max Technology 3.0 for improved performance.

Memory Support:

• Slots: 8 x DIMM
• Maximum Capacity: Up to 128GB
• Supported Memory Types: DDR4 (up to 3333 MHz overclocked)
• Memory Architecture: Quad-channel memory support with second-generation T-Topology for enhanced stability and performance.

Expansion Slots:

• 2 x PCIe 3.0 x16 slots (operating at x16 mode).
• 2 x PCIe 3.0 x16 slots (operating at x8 mode).
• 1 x PCIe 2.0 x4 slot for additional expansion cards.

Storage Options:

• M.2 Slot:
  • 1 x M.2 socket supporting PCIe SSDs (type 2260/2280/22110).
• U.2 Connector:
  • Supports NVMe storage devices.
• SATA Ports:
  • 10 x SATA III (6Gb/s) ports with RAID support (RAID 0, 1, 5, and 10).

Networking:

• LAN Controllers:
  • Dual Intel® Gigabit Ethernet (I218-V and I211-AT) for reliable networking.
• GameFirst Technology: Optimizes network traffic for smoother gameplay.

USB Connectivity:

• Multiple USB ports including:
  • 4 x USB 3.1 Gen 1 Type-A ports.
  • 2 x USB 3.1 Gen 2 Type-A ports.
  • 2 x USB Type-C ports.

Audio Features:

• Audio Codec: Realtek ALC1150 supporting up to 7.1-channel high-definition audio with Sonic Studio II for enhanced audio experience.

Additional Features:

• Aura RGB Lighting: Customizable RGB lighting with Aura Sync support for personalized aesthetics.
• SafeSlot Technology: Enhanced PCIe slot design for improved strength and durability.
• Premium Components: Carefully selected components to ensure maximum reliability and longevity.
