TP-Link TL-POE10R PoE Splitter

The TP-Link TL-POE10R is a versatile PoE splitter designed to provide power and data to non-PoE devices over Ethernet cables. This device is compliant with the IEEE 802.3af standard and is ideal for powering devices such as wireless access points, IP cameras, and VoIP phones in locations where power outlets are not available.

Key Features

• Gigabit Ethernet Support:
  • Equipped with 2 x 10/100/1000Mbps RJ45 ports that support auto-negotiation and auto-MDI/MDIX, ensuring compatibility with various network devices.
• Selectable Power Output:
  • Provides adjustable output options of 12VDC 1A, 9VDC 1A, or 5VDC 2A, allowing flexibility based on the requirements of the connected device.
• Long Distance Power Delivery:
  • Capable of delivering power up to 100 meters (328 feet) over Ethernet cables, making it suitable for installations in larger areas.
• Plug-and-Play Installation:
  • The TL-POE10R requires no configuration, allowing for easy installation and immediate use.
• LED Indicator:
  • Features a power LED indicator for monitoring the operational status of the device.

Technical Specifications

• Model: TP-Link TL-POE10R
• Power Supply Options:
  • Selectable output:
    • 12VDC, 1A
    • 9VDC, 1A
    • 5VDC, 2A
• Dimensions:
  • Approximately 81 x 54 x 24 mm (3.2 x 2.1 x 0.9 in).
• Operating Temperature:
  • Ranges from 0°C to +40°C (32°F to +104°F).
• Storage Temperature:
  • Ranges from -40°C to +70°C (-40°F to +158°F).
• Operating Humidity:
  • Humidity levels of 10% to 90% non-condensing.
• Certifications:
  • FCC, CE, RoHS compliant.

Package Contents

• TP-Link TL-POE10R PoE Splitter
• Power Cord
• RJ45 Cable
• Installation Guide
