TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch

The TP-Link TL-SF1016D is a reliable 16-port 10/100Mbps desktop switch designed for small office/home office (SOHO) or workgroup environments. This unmanaged switch provides an easy and efficient way to expand your wired network, ensuring robust connectivity and performance.

Key Features

• 16 Fast Ethernet Ports:
  • Equipped with 16 10/100Mbps RJ45 ports, all supporting auto MDI/MDIX, which eliminates the need for crossover cables and simplifies installation.
• High Performance:
  • The switch features a non-blocking architecture that forwards and filters packets at full wire-speed for maximum throughput. It can process data at a rate of up to 200 Mbps in full duplex mode.
• Energy-Efficient Design:
  • Incorporates innovative energy-saving technologies that automatically adjust power consumption based on link status and cable length, reducing overall energy costs by up to 80%.
• Plug and Play Installation:
  • The auto features of the switch make installation hassle-free with no configuration required. Simply plug in your devices, and the switch will automatically negotiate the best connection speed.

Specifications

• Model: TP-Link TL-SF1016D
• Ports:
  • 16 x 10/100Mbps Auto-Negotiation RJ45 ports
• Power Supply:
  • External power adapter (Output: 5V/0.6A)
• Dimensions:
  • Approximately 200 x 142 x 40 mm (7.9 x 5.6 x 1.6 in)
• Weight:
  • Approximately 0.75 kg

Performance

• Switching Capacity:
  • Up to 3.2 Gbps
• Forwarding Rates:
  • 10BASE-T: 14880 pps/port
  • 100BASE-TX: 148800 pps/port

Connectivity Features

• Standards Supported:
  • IEEE 802.3, IEEE 802.3u, IEEE 802.3x
• Transfer Method:
  • Store-and-forward

Package Contents

• TP-Link TL-SF1016D Switch
• Power Adapter
• User Guide
