TP-Link TL-SG1005D 5-Port Gigabit Desktop Switch

The TP-Link TL-SG1005D is a high-performance 5-port Gigabit desktop switch designed to facilitate the transition to Gigabit Ethernet for home and small office networks. This unmanaged switch offers an easy and cost-effective solution for expanding your wired network with high-speed connections.

Key Features

• 5 Gigabit Ports:
  • Equipped with 5 x 10/100/1000Mbps RJ45 ports, supporting auto-negotiation and Auto-MDI/MDIX, which eliminates the need for crossover cables and simplifies installation.
• Energy-Efficient Design:
  • Incorporates innovative Green Ethernet technology that can save up to 85% of power consumption, making it an eco-friendly choice for your network.
• Fanless Operation:
  • The fanless design ensures quiet operation, making it suitable for noise-sensitive environments.
• Plug and Play Installation:
  • Simple setup with no configuration required; just connect your devices and start using the network immediately.
• Reliable Performance:
  • Supports IEEE 802.3x flow control for stable data transfer, ensuring efficient communication between connected devices.

Specifications

• Model: TP-Link TL-SG1005D
• Ports:
  • 5 x 10/100/1000Mbps Auto-Negotiation RJ45 ports
• Power Supply:
  • External power adapter (Output: 5V DC / 0.6A)
• Dimensions:
  • Approximately 140 x 88 x 23 mm (5.5 x 3.5 x 0.9 in)
• Max Power Consumption:
  • Maximum: 3W (220V/50Hz)

Performance

• Switching Capacity:
  • Up to 10 Gbps
• Packet Forwarding Rate:
  • Up to 7.4 Mpps
• MAC Address Table:
  • Supports up to 2K MAC addresses
• Jumbo Frame Support:
  • Up to 15 KB, improving performance for large data transfers.

Connectivity Features

• Standards Supported:
  • Compliant with IEEE 802.3, IEEE 802.3u, and IEEE 802.3x.

Package Contents

• TP-Link TL-SG1005D Switch
• Power Adapter
• Quick Installation Guide
