TP-Link TL-SG1008D 8-Port Gigabit Desktop Switch

The TP-Link TL-SG1008D is an efficient 8-port Gigabit desktop switch designed to facilitate the transition to Gigabit Ethernet in home and small office networks. This unmanaged switch provides a simple and effective way to expand your network capacity, enabling faster data transfer and improved performance.

Key Features

• 8 Gigabit Ports:
  • Equipped with 8 x 10/100/1000 Mbps RJ45 ports, supporting auto-negotiation and Auto-MDI/MDIX, which eliminates the need for crossover cables and simplifies installation.
• Energy-Efficient Design:
  • Utilizes Green Ethernet technology that can save up to 80% of power consumption, making it an eco-friendly solution for your network.
• Fanless Operation:
  • The fanless design ensures silent operation, making it suitable for noise-sensitive environments.
• Plug and Play Installation:
  • Simple setup with no configuration required; just connect your devices and start using the network immediately.
• Reliable Performance:
  • Supports IEEE 802.3x flow control for stable data transfer, ensuring efficient communication between connected devices.

Specifications

• Model: TP-Link TL-SG1008D
• Ports:
  • 8 x 10/100/1000 Mbps Auto-Negotiation RJ45 Ports
• Power Supply:
  • External power adapter (Output: 9V DC / 0.6A)
• Dimensions:
  • Approximately 180 x 90 x 25.5 mm (7.1 x 3.5 x 1.0 in)
• Max Power Consumption:
  • Maximum: 4.63W (220V/50Hz)

Performance

• Switching Capacity:
  • Up to 16 Gbps
• Packet Forwarding Rate:
  • Up to 11.9 Mpps
• MAC Address Table:
  • Supports up to 4K MAC addresses
• Jumbo Frame Support:
  • Up to 15 KB, enhancing performance for large data transfers.

Connectivity Features

• Standards Supported:
  • Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, and IEEE 802.3x.

Package Contents

• TP-Link TL-SG1008D Switch
• Power Adapter
• Quick Installation Guide
